Repair Kit
5-1050
Complete rebuild kit for 10" turbine flow meters. Includes rotor, vanes, bearings, and hardware.
10"
Meter Size
1.6
K-Factor (PPG)
147
Max Pulses/Sec
Calibration Data for 10" Meters
1.6
K-Factor (PPG)
147
Max Pulses/Sec
±0.1%
Linearity
-40°/250°F
Temp Range
Note: These are nominal calibration values. Your meter's specific K-factor is printed on its calibration tag. Always use the exact value from your meter for best accuracy.
Kit Contents
Rotor Assembly
Upstream Vane
Downstream Vane
Tungsten Carbide Bearings
Shaft
Snap Rings / Hardware
Installation Instructions
View step-by-step repair kit installation guide for 4" & Up meters with diagrams.
Compatible 10" Meters
This repair kit fits all 10" Wagner Flow turbine meters, including:
Threaded NPT
Flanged (150#, 300#, 600#)
Between Flange
Ring Joint
Need Help Selecting the Right Kit?
Not sure which repair kit you need? We can help identify the correct kit based on your meter's model number or serial number.
