Between Flange Meter
6-10000
FLOW RATE: 500-5500 GPM 10" x 10" BETWEEN FLANGE FLOW METER WITH RAISED FACE ENDS
500-5500 GPM
Flow Range
10"
Internal Size
Don't Forget!
Add a Magnetic Pickup
Required for all totalizer setups. The 4-303 is the recommended pickup for this meter.
View 4-303
$46.00
Specifications
500-5500 GPM
Flow Range
±1%
Accuracy
±0.1%
Repeatability
316 SS
Body Material
Calibration Data
1.6
K-Factor (PPG)
147
Pulses per Sec
±0.1%
Linearity
-40°/250°F
Temp Range
Compatible Accessories
Applications
Oilfield Waterflood
Production Metering
Well Servicing
Pipeline Transfer
Mining Operations
Chemical Processing
Questions About This Meter?
Our team is ready to help with sizing, specifications, and custom requirements.
