3-0750-300 - Wagner Flow Turbine Flow Meter
Flanged Meter

3-0750-300

FLOW RATE: 2-15 GPM 3/4" X 3/4" FLOW METER W/ 300 SERIES RAISED FACE FLANGES

2-15 GPM Flow Range
720 PSI Max Pressure
3/4" Internal Size
$1,960.00
Request Quote
Don't Forget!

Add a Magnetic Pickup

Required for all totalizer setups. The 4-5050 is the recommended pickup for this meter.

Specifications

2-15 GPM
Flow Range
720 PSI
Max Pressure
±1%
Accuracy
±0.1%
Repeatability
316 SS
Body Material

Calibration Data

2,950
K-Factor (PPG)
740
Pulses per Sec
±0.1%
Linearity
-40°/250°F
Temp Range

Applications

Oilfield Waterflood Production Metering Well Servicing Pipeline Transfer Mining Operations Chemical Processing

Questions About This Meter?

Our team is ready to help with sizing, specifications, and custom requirements.
