Magnetic Pickups
Magnetic pickups detect rotor rotation and are required for all totalizer setups. Select based on your meter size: 4-303 for 7/8" and larger meters, 4-5050 for 3/4" and smaller.
| Part # | Description | Price | |
|---|---|---|---|
| 4-5060 | EDD Gas Magnetic Pickup, 1.13 inch x 5/8-18 UNF threads. Compact design for gas meter applications. | $95.50 | |
| 4-5045 | EDD Amplified Magnetic Pickup, 3.5 inch thread length x 5/8-18 UNF threads. Extended reach design. | $260.50 | |
| 4-5031SE-24 | EDD 3-Pin Voltage Tracking Magnetic Pickup with sealed end. Extended thread length for deep insta... | $441.00 | |
| 4-5030 | EDD Amplified Magnetic Pickup, 3 inch x 5/8-18 UNF threads. 3-pin connector with 0-10V NPN square... | $317.00 | |
| 4-5019 | EDD Amplified Magnetic Pickup, 5 inch thread length x 5/8-18 UNF threads. Extended reach for gear... | $417.50 | |
| 4-5017 | EDD Amplified Magnetic Pickup with 3/4-20 threads. 3-pin connector with 0-10V NPN square wave out... | $254.50 | |
| 4-5016 | EDD Amplified Magnetic Pickup, 4 inch x 5/8-18 UNF threads. 3-pin connector with 0-10V NPN square... | $386.00 | |
| 4-5050 | MAGNETIC PICKUP FOR METERS 3/4" & SMALLER, 1.13" x 5/8"-18 UNF THREADS | $76.50 | |
| 4-5024 | 4.5024 Digital Magnetic Pickup | $290.50 | |
| 4-302T800 | 4.302T800 High Temperature Magnetic Speed Sensor | $765.50 | |
| 4-201 | MAGNETIC PICKUP LOCK NUT, 5/8"-18 UNF THREADS | $2.50 | |
| 4-204 | MAGNETIC PICKUP, 2 PIN, 3" THREAD LENGTH 600 OHM COIL | $206.00 | |
| 4-303 | MAGNETIC PICKUP FOR METERS 7/8" & UP, 5/8"-18 UNF THREADS, 2.25" OVERALL LENGTH | $46.00 | |
| 4-303-3 | MAGNETIC PICKUP FOR METERS 7/8" & UP, 3" x 5/8"-18 UNF THREADS, 4.15" OVERALL LENGTH | $236.00 | |
| 4-3030HTB | HIGH TEMPERATURE MAGNETIC PICKUP, 1.35" x 5/8"-18 UNF THREADS | $187.50 | |
| 4-304 | MAGNETIC PICKUP, 1.75" x 5/8"-18 UNF THREADS, 3" OVERALL LENGTH | $120.50 | |
| 4-306 | MAGNETIC PICKUP 4" THREAD LENGTH, 4" x 5/8"-18 UNF THREADS, 5.15" OVREALL LENGTH | $257.50 | |
| 4-307 | MAGNETIC PICKUP, 5" x 5/8"-18 UNF THREADS, 6.25" OVERALL LENGTH | $310.00 | |
| 4-5015-24FM | FACTORY MUTUAL AMPLIFIED MAGNETIC PICKUP-3 PIN SUPPLY VOLTAGE TRACKING | $584.00 | |
| 4-5015U | AMPLIFIED MAGNETIC PICKUP, 1.63" x 5/8"-18 UNF THREADS, 3" OVERALL LENGTH, 3 PINS | $172.50 | |
| 4-5031SE | SEALED END MAGNETIC PICKUP, 3" x 5/8"-18 UNF THREADS | $329.00 | |
| 4-N40-21 | PICKUP NON INCENDIVE CSA APPROVED SUBSTITUTE FOR 4.303 | $295.50 | |
| 4-N4027C | 4-20 MA MODULE IN CONDULET HOUSING NON INCENDIVE CSA APPROVED SUBSTITUTE FOR 4.0420C | $485.00 | |
| 4-301 | PICKUP RING 5/8-18" THD | $14.00 | |
| 4-5015-24 | AMPLIFIED MAGNETIC PICKUP-3 PIN SUPPLY VOLTAGE TRACKING, 3" OVERALL LENGTH | $172.50 | |
| 4-5019-24 | AMPLIFIED MAGNETIC PICKUP, SEALED END, 5" X 5/8"-18 UNF THREADS, VOLTAGE TRACKING | $438.00 | |
| 4-5019SE | AMPLIFIED MAGNETIC PICKUP, SEALED END, 5" X 5/8"-18 UNF THREADS | $507.50 | |
| 4-5030-24 | AMPLIFIED MAGNETIC PICKUP-3 PIN SUPPLY VOLTAGE TRACKING, 3" X 5/8-18" UNF THREADS, 4" OVERALL LENGTH | $343.50 | |
| 4-5031SE-FMA | SEALED END MAGNETIC PICKUP, 3" x 5/8"-18 UNF THREADS, ATEX CERTIFIED | $659.00 | |
| 4-5033SE | SEALED END MAGNETIC PICKUP, 6" x 5/8"-18 UNF THREADS | $553.50 |
